Motoruitschakeling

selectie

Beschrijving

Motoruitschakeling op afstand wordt gebruikt om de motor uit te schakelen zonder de contactsleutel naar de vergrendelde stand te hoeven draaien, bijvoorbeeld met behulp van een schakelaar buiten de cabine.

Geschikt voor toepassingen als:

  • Betonmixerwagens
  • Vrachtwagens met kraan

Functie

De motor start als een laag of hoog signaal 1 wordt geactiveerd via pen 10 (optioneel) in stekkerverbinding C259.

Een geschikte oplossing om signalen buiten de cabine te kunnen ontvangen is het aansluiten van een kabelboom voor carrosseriefuncties op stekkerverbinding C494. De kabelboom wordt vertakt naar de 3 DIN-stekkerverbindingen C486, C487 en C488.

Meer informatie vindt u in de volgende documenten:

Motoruitschakeling op afstand
Kabelboom voor carrosseriefuncties
Kabelboomconnector C494 - Carrosseriefuncties

1. Moet vooraf zijn ingesteld in BICT

Download Logic Diagram for Engine Shutdown
